The BORDO MAG 50 is a corded magnetic base drill designed for professional metalworkers and fabricators requiring precision drilling and countersinking up to 50mm diameter. It is engineered to meet Australian electrical safety standards AS/NZS 4417.1 and AS/NZS 4417, ensuring compliance with RCM and EESS regulations.

This magnetic drill offers a versatile solution with a wide range of compatible cutter diameters and an extended stroke length, positioning it as an efficient tool for production environments. Its powerful magnet provides strong adhesion to ferrous surfaces, enabling stable and accurate drilling of larger diameter holes. The two-speed gearbox supports heavy-duty cutting tasks, delivering speeds of 235 and 425 RPM under load for optimal performance.

• Annular cutter diameter range: 12-50 mm
• Twist drill diameter range: 1-20 mm
• Countersink diameter range: 10-55 mm
• Stroke length: 155 mm
• Magnet force: 1600 kg
• Motor power: 1200 W
• Dimensions (LxWxH): 320 x 200 x 378-533 mm
• Weight: 13.5 kg
• Spindle type: 19.05 mm Weldon
• Power supply: 220-240V, 50/60Hz

The BORDO MAG 50 magnetic base drill is ideal for drilling and countersinking applications in steel fabrication, construction, and industrial maintenance, providing reliable performance and compliance with safety standards.
