The FRONIUS FPA 3020 Orbital Power Source & Controller is a specialized welding power source designed for automated orbital welding applications, primarily used in industries requiring precise and repeatable welds such as aerospace, pharmaceutical, and piping fabrication.

This unit integrates a PLC controller with simple programming capabilities and an inverter power source delivering 3 to 200 amps AC/DC output, suitable for a wide range of welding tasks. It features a touch screen display for intuitive operation, a built-in printer for documentation, and a USB interface allowing program backup and transfer via USB stick. The internal memory can store up to 200 welding programs, enhancing workflow efficiency.

Included is a remote control unit (FRC-FPA3020) with a 10-meter cable for flexible operation. The system incorporates an integrated water cooler to maintain optimal operating temperatures, along with gas flow control and a water flow switch to ensure process stability and safety. It operates on single-phase 240V power and weighs 32 kg. Additionally, the package includes an argon regulator of the bobbin type, essential for shielding gas control during TIG welding.

• PLC controller with easy programming
• Integrated inverter power source: 3–200 amps AC/DC
• Touch screen interface and built-in printer
• USB interface with backup capability
• Internal memory for 200 programs
• Remote control unit with 10 m cable
• Integrated water cooler for thermal management
• Gas flow control and water flow switch
• Single-phase 240V operation
• Weight: 32 kg
• Includes bobbin-type argon regulator
